The AVE Digi4 Mini Digital Mixer (4-Channel) is a multi-purpose 4-channel USB sound card control console for recording, playback, live webcasting and mixing production. It provides 24-bit/48kHz resolution, 2-channel OTG recording and playback, LOOPBACK functionality and stereo dual-mode Bluetooth V5.0 input. The MIC1 channel includes +48V phantom power, while the GUITAR 2 channel has an independent sensitivity control knob for guitar input. Control and monitoring are provided by a 2.8-inch touch high-definition color LCD display.
AVE Digi4 Mini Digital Mixer (4-Channel)
RRP: $209.00 ex. GST
Key Features:
- 24-bit/48kHz resolution with 2-channel OTG recording and playback
- LOOPBACK function for recording and live webcasting
- MIC1 channel with +48V phantom power supply
- GUITAR 2 channel with independent sensitivity control knob
- Stereo dual-mode Bluetooth V5.0 input
- 2.8-inch touch high-definition color LCD display screen
- TYPE C USB (+5V) power supply
Technical Data
| Type | Balanced Combo |
| System specs | 24-bit A/D and D/A conversion, with a sampling rate of 48kHz |
| MIC input | 6.3mm JACK |
| Phantom power | +48V DC |
| GUITAR input | HIGH I IN |
| Main output | Balanced 6.3mm jack, maximum +12dBu |
| OTG USB audio | 2.0, 2 independent OTG (TYPE-C) recording interfaces |
| Bluetooth | Stereo dual-mode Bluetooth V5.0 input |
| Display screen | 2.8-inch color high-definition screen |
| Power | DC 5V, 2000mA |
| Dimensions (L*W*H) | 140*63*205 mm |
| Weight | 1.19 kg |
