Chamsys MagicQ Stadium Connect is a PC-based programming interface for MagicQ Stadium Software, with the same programming keyset and dual crossfaders as the MQ250M and MQ500M. It provides 64 universes directly from MagicQ PC via Art-Net, sACN and Pathport, plus up to 400 visualisation universes for pre-programming. The controller includes 10 fully motorised fader playbacks, 10 encoder playbacks, backlit buttons and RGB-controlled playback illumination. MagicQ Stadium Software includes an audio timeline editor, multi emitter colour picker, 3D trackers support and plot.
Chamsys MagicQ Stadium Connect Lighting Controller
RRP: $13,999.00 ex. GST
Key Features:
- 64 universes direct from MagicQ for Art-net/sACN output
- 400 visualisation universes for pre-programming
- 10 fully motorised fader playbacks
- 10 encoder playbacks
- Dual 100mm Manual Cross Faders
- Illuminated Playback/Encoders with RGB control
- Backlit buttons
Technical Data
| Direct DMX Outputs | 4 |
| Motorised Playbacks | 10 |
| Encoder Playbacks | 10 |
| Total no of Playbacks | 20 (10+10) |
| Dual Cross Faders | Yes |
| Attribute Encoders | 4 |
| Backlit Keys | Yes |
| Illuminated Playback/Encoders with RGB control | Yes |
| Intensity Wheel | 1 |
| Network Ports | 1 |
| USB Ports | 4 |
| Audio Input Sound to Light | Yes |
| MIDI Ports | 1 in and out |
| LTC Timecode Ports | in and out |
| 10Scene Port | 1 |
| Power Input | Neutrik powerCON TRUE1 110 to 240 VAC |
| Max Power Consumption (mains) | 360w |
| Universes direct from software (via Artnet/sACN/Pathport) | 64 |
| Visualisation Universes | 400 |
| Max Number of DMX Channels | 204,800 |
| Max Number of Fixtures Supported | 204,800 |
| Max Number of Cues | 5000 |
| Max Number of Cue Stacks | 2000 |
| Max Number of Groups | 5000 |
| Max Number of Palettes | 4096 |
| Number of Media Server Layers Supported | 50 (each different content) |
| Supported on | Windows (8.1 or higher), macOS (12 or higher) and Linux |
| Width (Stadium Connect) | 680mm (26.8″) |
| Depth (Stadium Connect) | 364mm (14.3″) |
| Height (Stadium Connect) | 85mm (3.3″) |
| Weight (Stadium Connect) | 8.7kg (19.1lbs) |
| Width (Flight Case) | 761mm (29.9″) |
| Depth (Flight Case) | 467mm (18.3″) |
| Height (Flight Case) | 197mm (7.7″) |
| Weight (Flight Case) | 20.0kg (44.1lbs) |
