The Chauvet Pro ÉPIX Drive 2000 IP is an IP65-rated processor and power supply for ÉPIX IP and Tour systems. It drives up to 2000 LEDs and provides 20 total Art-Net/sACN universes for pixel mapping. Control is available through Art-Net, Kling-Net, and sACN, with automatic fixture detection and an onboard OLED touchscreen. A built-in web server supports remote system management and diagnostics, while unshielded cable runs can extend up to 150 ft (45 m) from the processor to the first fixture.
Chauvet Pro ÉPIX Drive 2000 IP IP65 LED Pixel-Mapping Processor and Power Supply
RRP: $2,510.00 ex. GST
Key Features:
- IP65-rated processor and power supply for ÉPIX IP and Tour systems
- 20 total Art-Net/sACN universes, with 10 Art-Net/sACN universes per port
- Drives up to 2000 LEDs
- Supports up to 20 ÉPIX Strip IPs or 36 ÉPIX Strip Tours
- Art-Net, Kling-Net, and sACN control protocols
- Onboard OLED touchscreen and automatic fixture detection
- Built-in web server for remote system management and diagnostics
- Maximum unshielded cable length of 150 ft (45 m) between the ÉPIX Drive 2000 and first ÉPIX Tour or IP fixture
Technical Data
| Weight | 12 lb (5.4 kg) |
| Exterior Color | Black |
| Housing Material | Aluminum |
| Rackmount | 2U |
| Control Protocol | Art-Net, Kling-Net, sACN |
| Control Universes | 10 Art-Net/sACN Universes per port (20 total per device) |
| Control Channels (Art-net, sACN) | 7, 8, 15, 30, 75, or 150 |
| Input Voltage | 100 to 240 VAC, 50/60 Hz (auto-ranging) |
| Output Voltage | 48 VDC |
| Maximum Load | 10 ÉPIX Strip IP or 18 ÉPIX Strip Tour or 6 ÉPIX Bar Tour (per output) |
| Device Outputs (4-pin XLR) | 2 |
| Power Input | Seetronic Powerkon IP65 |
| Power Output | Seetronic Powerkon IP65 |
| Data Connectors | Seetronic Etherkon IP65 |
| IP Rating | IP65, outdoor/wet, with pressure equalizing M12 GORE® valve |
| Temperature (Ambient) | -4 °F to 113 °F (-20 °C to 45 °C) |
| Certifications | CE, MET |
| Power Linking | 3 units @ 120 V; 5 units @ 208 V; 5 units @ 230 V |
| Total max. cable length (shielded cables) between ÉPIX Drive 2000 and last ÉPIX Tour or IP fixture | 210 ft (64 m) |
| Total max. cable length (unshielded cables) between ÉPIX Drive 2000 and last ÉPIX Tour or IP fixture | 300 ft (91 m) |
