The Faital Pro 21XL3000 (8Ω) Low-Frequency Neodymium Loudspeaker is a 21-inch loudspeaker designed for low-frequency applications. It has an 8 Ohm nominal impedance, 3000 W AES power handling, and a 98 dB sensitivity rating. The frequency range is 30÷1500 Hz, with a 1.4 T flux density. Construction includes a Neodymium Ring magnet, Aluminum Ring demodulation, an aluminum basket, and a Triple Roll cone surround.
Faital Pro 21XL3000 (8Ω) Low-Frequency Neodymium Loudspeaker
RRP: $2,499.00 ex. GST
Key Features:
- 3000 W AES Power Handling
- 98 dB Sensitivity (1W/1m)
- 30÷1500 Hz Frequency Range
- Neodymium Ring Magnet
- Aluminum Ring Demodulation
- Triple Roll Cone Surround
Technical Data
| Nominal Diameter | 535 mm (21 in) |
| Overall Diameter | 547 mm (21.54 in) |
| Bolt Circle Diameter | 527 mm (20.75 in) |
| Baffle Cutout Diameter | 508 mm (20.00 in) |
| Depth | 279.5 mm (11.00 in) |
| Flange and Gasket Thickness | 16 mm (0.63 in) |
| Net Weight | 21.5 kg (47.4 lb) |
| Nominal Impedance | 8 Ohm |
| Minimum Impedance | 7 Ohm |
| AES Power Handling (1) | 3000 W |
| Maximum Power Handling (2) | 6000 W |
| Sensitivity (1W/1m) | 98 dB |
| Frequency Range | 30÷1500 Hz |
| Voice Coil Diameter | 165 mm (6.5 in) |
| Winding Material | Aluminium |
| Former Material | Glass Fiber |
| Winding Depth | 40 mm (1.57 in) |
| Magnetic Gap Depth | 14 mm (0.55 in) |
| Flux Density | 1.4 T |
| Magnet | Neodymium Ring |
| Basket Material | Aluminum |
| Demodulation | Aluminum Ring |
| Cone Surround (3) | Triple Roll |
| NET Air Volume filled by Loudspeaker | 13.0 dm^3 (0.459 ft^3) |
| Spider Profile | 2x non-adjacent constant height waves |
| Fs | 30 Hz |
| Re | 5.9 Ohm |
| Qes | 0.25 |
| Qms | 8.8 |
| Qts | 0.25 |
| Vas | 284.6 dm^3 (10.05 ft^3) |
| Sd | 1744 cm^2 (270.32 in^2) |
| Xmax (4) | 17.67 mm |
| Xdamage (5) | 40 mm |
| Mms | 420.0 g |
| Bl | 43.0 N/A |
| Le | 1.25 mH |
| Mmd | 337.7 g |
| Cms | 0.07 mm/N |
| Rms | 9.0 kg/s |
| Eta Zero | 3.0 % |
| EBP | 119 Hz |
