The Hazebase Base Touring2 is a dual-purpose fog and haze generator built for arenas, touring stages, and broadcast environments. Combining a powerful 6,200 W heater block with an integrated 450 W fan, it produces stadium-scale atmospherics ranging from dense fog bursts to refined, continuous haze. Despite its massive output, the unit reaches full readiness in under 14 minutes, ensuring productions never face delays. Control is flexible and precise: operators can integrate the Touring2 via a single DMX channel, use analog 0–10 V input, or rely on the internal timer for stand-alone operation. Optional wired and wireless remotes provide additional convenience for touring crews. Designed for durability, the rugged chassis includes dual 10 L fluid tanks, microprocessor-based temperature regulation, and multiple thermal protection layers. Optimized for Hazebase’s pharmaceutical-grade water-based fluids, the Touring2 delivers reliable performance with low residue, extended run times, and minimal maintenance—making it a touring essential.
Hazebase Base Touring2 Fog and Hazer Machine
RRP: $15,999.00 ex. GST
Key Features:
- 3100 W (single) or 6200 W (dual) heater blocks deliver stadium-filling fog in seconds
- Integrated 450 W variable-speed fan projects dense output further & faster
- Reaches full operating temperature in under 14 minutes for rapid deployments
- Single-channel DMX, on-board timer, or optional wired/wireless remotes provide flexible control
- Microprocessor-driven temperature regulation and multiple thermal safeguards
- Dual 10 L tanks and efficient 120–240 ml/min consumption maximize show uptime
Technical Data
| Procedure: | Vaporizing fog generator |
|---|---|
| Power Supply: | 230 V AC, 50 Hz |
| Heater Power: | 1 × 3100 W (single) or 2 × 3100 W (dual) |
| Fan Power: | 450 W controllable |
| Power Requirement: | Up to 6200 W + 450 W fan |
| Air Volume: | Max. 1680 m³/h |
| Warm-up Time: | ≈ 14 min |
| Fluid Tank Capacity: | 2 × 10 L |
| Fluid Consumption: | 120 ml/min (min) – 240 ml/min (max) |
| Fog Output: | 0–99 % in 1 % steps |
| Fogging Time: | 60 s at 100 % output; continuous below 50 % |
| Control Options: | DMX-512 (1 ch.), 0–10 V analog, internal timer, optional remotes |
| Temperature Control: | Microprocessor-controlled |
| Overheating Protection: | Heater thermostat & pump thermal switch |
| Dimensions (L × W × H): | 750 × 573 × 900 mm |
| Weight: | 75 kg (single) / 87 kg (dual) |
| Fluid Type: | Pharmaceutical-grade water-based haze/fog fluid |
