The Laserworld CS-12.000RGB ShowNET is a compact, professional-grade laser projector delivering 12 W of pure-diode RGB power. Its balanced diodes (3 W red, 3 W green, 6 W blue) combine for vivid full-spectrum color, while precision 30 kpps scanners reproduce text, logos, and animations with sharp accuracy. Thanks to analog modulation, the system offers smooth dimming and fine brightness gradations—ideal for atmospheric effects or bold, high-contrast graphics. Control is simple and flexible with the built-in ShowNET mainboard. Users can program over ILDA, operate via DMX or ArtNet, or run it stand-alone using an onboard library of roughly 130 preset tunnels, waves, and abstract patterns. Custom animations can be uploaded directly to internal memory and triggered instantly, no external DAC required. Engineered for real-world environments, the CS-12.000RGB comes in an IP54-rated housing with isolated cooling fins to reduce maintenance. A 360° mounting bracket supports versatile installation, while a front masking plate enhances safety during operation.
Laserworld CS-12.000RGB ShowNET
RRP: $3,699.00 ex. GST
Key Features:
- 12 000 mW pure-diode RGB output for vivid, balanced color mixing
- Integrated ShowNET mainboard with ILDA, DMX, ArtNet & LAN control
- Ca. 130 pre-stored beam, wave and tunnel effects plus basic graphics
- 30 kpps @ 8° graphics-capable scanners for smooth projections
- Rugged IP54 enclosure with separate cooling fin compartment
- Analog modulation & beam masking plate for precise brightness control
- 360° mounting bracket ideal for truss, ceiling or mobile setups
- Includes free laser show control software and accessories
Technical Data
| Guaranteed Output Power: | 12 000 mW |
|---|---|
| Red Laser Source: | 3 000 mW / 638 nm |
| Green Laser Source: | 3 000 mW / 520 nm |
| Blue Laser Source: | 6 000 mW / 450 nm |
| Beam Specifications: | 5 mm / 1.2 mrad |
| Scanner Speed: | 30 kpps @ 8° (max 40° angle) |
| Laser Source Type: | Pure diode, analog modulation |
| Laser Class: | 4 |
| Control Interfaces: | ILDA, DMX, ArtNet, LAN, ILDA streaming, stand-alone, SD card |
| Pre-stored Patterns: | Ca. 130 (layers, tunnels, fences, waves, etc.) |
| Enclosure Rating: | IP54 |
| Power Supply: | 85–250 V AC, 50/60 Hz |
| Power Consumption: | 150 W |
| Dimensions: | 285 × 180 × 190 mm |
| Weight: | 7.7 kg |
| Included Accessories: | Power cable, manual, interlock, key |
