The Laserworld DS-3000RGB MK5 is a professional 3 W RGB pure-diode laser projector that combines precision output with advanced connectivity. Powered by 650 mW of red at 638 nm, 900 mW of green at 520 nm, and 1,600 mW of blue at 450 nm, it guarantees a balanced 3,000 mW total output. A 4 mm beam diameter with ultra-low 0.9 mrad divergence ensures sharp graphics and aerial effects, while 40 kpps scanners deliver smooth animations across a wide 40° angle. Its integrated ShowNET control platform provides ILDA, LAN, ArtNET, and DMX operation, with two DMX profiles: DJ Mode for ease of use and Professional Mode for full creative control. More than 120 preloaded patterns can run in stand-alone or sound-to-light modes. Housed in a sealed aluminium enclosure, the DS-3000RGB MK5 minimizes dust and maintenance while offering safety features like scan-fail detection, output limiting, and password protection—ideal for touring and permanent installations.
Laserworld DS-3000 RGB ShowNET Laser System MK5
RRP: $2,899.00 ex. GST
Key Features:
- 3,000 mW pure-diode RGB output with vivid analog colour mixing
- Integrated ShowNET DAC & free Showeditor software licence
- Dual DMX modes plus ArtNET, ILDA, LAN & stand-alone operation
- Precision 4 mm / 0.9 mrad beams & 40 kpps@8° graphics scanning
- Sealed Housing with scan-fail & output-limit safety presets
Technical Data
| Guaranteed Output: | 3,000 mW |
|---|---|
| Red Diode Power / Wavelength: | 650 mW / 638 nm |
| Green Diode Power / Wavelength: | 900 mW / 520 nm |
| Blue Diode Power / Wavelength: | 1,600 mW / 450 nm |
| Beam Diameter / Divergence: | ≈4 mm / 0.9 mrad (full angle) |
| Scanner Speed: | 40 kpps @ 8° |
| Max Scan Angle: | 40° |
| Control Modes: | ILDA, DMX (2 modes), ArtNET, LAN, Stand-alone, Sound-to-Light |
| Integrated Memory: | >120 patterns + SD card for user content |
| Safety Features: | Scan-fail protection, output limit, key switch & interlock |
| Housing: | Sealed optics section, low maintenance |
| Power Supply: | 85–250 V AC, 50/60 Hz |
| Power Consumption: | 80 W |
| Dimensions (L×W×H): | 210 × 215 × 142 mm |
| Weight: | 5.5 kg |
