The Laserworld FX GOBO Wheel is a compact yet powerful accessory that instantly expands the creative potential of compatible laser projectors. Equipped with three premium glass gratings—burst, line, and lumia—plus an open position, it transforms standard beams into immersive patterns ranging from sharp multi-line projections to fluid wave-like textures and swirling atmospheric striae. These effects deliver stunning visual variety for clubs, stages, and installations. Full DMX control provides dynamic performance, allowing users to adjust rotation direction, variable speeds, and trigger rapid gobo-shake effects for strobing refraction in sync with music. This makes the FX GOBO Wheel a versatile tool for both subtle ambience and high-energy shows. Engineered for effortless integration, the unit mounts directly in front of Laserworld and tarm projectors or other models with a compatible aperture size. Lightweight at just 1.5 kg, with a wide 55° scan angle and universal 85–250 V AC input, it’s road-ready and adaptable worldwide.
Laserworld Gobo Wheel Attachment for DS PL and TARM laser systems
RRP: $1,399.00 ex. GST
Key Features:
- DMX-controllable glass wheel offers three diffraction gratings plus open for versatile beam patterns
- Bidirectional rotation with variable speed enables dramatic gobo-shake and burst effects
- Generous 55° maximum scan angle floods stages and venues with vivid laser refractions
- Fits seamlessly on most Laserworld, tarm and many third-party laser projectors, model FXGOBO
- Compact 30 W design with 85–250 V auto-ranging PSU for hassle-free touring and installs
Technical Data
| Max. Scan Angle: | 55° |
|---|---|
| Operation Modes: | DMX |
| Basic Patterns: | 3 diffraction gratings (burst, line, lumia) + open |
| Power Supply: | 85 V – 250 V AC, 50/60 Hz |
| Power Consumption: | 30 W |
| Dimensions: | 240 × 170 × 120 mm |
| Weight: | 1.5 kg |
