The Laserworld PL-20.000RGB FB4 IP65 is a professional 20 W full-colour laser projector designed for maximum brightness, precision and durability in any setting. Its IP65-rated sealed aluminium housing with passive cooling protects against dust, moisture and weather, making it ideal for outdoor installations, touring productions, rental fleets and large indoor venues. Powered by three high-output diode modules—6 W red (638 nm), 8 W green (520 nm) and 8 W blue (450 nm)—the system delivers vivid, well-balanced colours. A narrow 6.5 mm beam with 0.9 mrad divergence ensures razor-sharp effects and long-distance projections, while 35 kpps scanners produce fluid graphics, text and animations across a 50° field. With the integrated Pangolin FB4 interface, users can run shows in standalone mode, trigger via DMX or ArtNet, or connect over LAN for QuickShow or BEYOND programming. Each unit includes a waterproof flightcase and 360° mounting bracket for flexible, tour-grade use.
Laserworld PL-20.000RGB FB4 IP65
RRP: $16,299.00 ex. GST
Key Features:
- 20 W full-colour RGB output (6W red, 8W green, 8W blue)
- Weatherproof IP65 sealed housing with efficient fanless cooling
- Built-in Pangolin FB4 enables DMX, ArtNet, network & stand-alone control
- 35 kpps scanners with 50° scan angle for crisp graphics & animations
- Includes 360° mounting bracket & waterproof flightcase for easy transport
Technical Data
| Guaranteed Output Power: | 20 000 mW |
|---|---|
| Red Power: | 6 000 mW / 638 nm |
| Green Power: | 8 000 mW / 520 nm |
| Blue Power: | 8 000 mW / 450 nm |
| Beam Diameter: | 6.5 mm |
| Beam Divergence: | 0.9 mrad |
| Scanner Speed: | 35 kpps @ 8° |
| Max Scan Angle: | 50° |
| Laser Source: | Diode |
| Laser Class: | 4 |
| Control Modes: | ILDA, DMX, ArtNet, LAN, Stand-alone |
| IP Rating: | IP65 |
| Power Supply: | 85–250 V AC, 50/60 Hz |
| Power Consumption: | 750 W |
| Dimensions: | 427 × 280 × 220 mm |
| Weight: | 26 kg |
