Laserworld PL-70.000RGB FB4 IP65

SKU: PL-70000RGBIP65-FB4 Category: Tag

RRP: $34,999.00 ex. GST

Key Features:
  • 70 000 mW guaranteed full-colour output for large venues
  • Built-in Pangolin FB4 for DMX, ArtNet, LAN & standalone control
  • IP65 sealed housing with external cooling fins for outdoor reliability
  • Precision 10 mm / 1.1 mrad beam and 30 kpps scanners up to 60°
  • Separate optics compartment keeps maintenance minimal
  • 360° mounting bracket and linkable power/DMX/ILDA
  • Safety settings stored on board for every operating mode
  • Includes waterproof flightcase

The Laserworld PL-70.000RGB FB4 IP65 is a powerhouse laser projector delivering an extraordinary 70 W of RGB output for large-scale shows, stadiums and festivals. Its advanced diode arrays (29 W each for red, green and blue) ensure brilliant full-colour mixing, while the 10 mm / 1.1 mrad beam and 30 kpps scanners deliver crisp graphics, smooth text and sharp aerial effects even across long throw distances. Control is highly versatile with the integrated Pangolin FB4 interface, offering DMX, ArtNet, ILDA, LAN and stand-alone playback via SD card. Compatible with QuickShow and BEYOND, it adapts to both automated and live show workflows. On-board safety settings remain active across all modes, and multiple units can be daisy-chained for simplified multi-projector installations. Designed for the toughest environments, its IP65-rated housing, external cooling fins and sealed optics chamber ensure low maintenance and weather resistance. A 360° mounting bracket and rugged waterproof flightcase make it fully tour-ready.

Technical Data

Guaranteed Output Power: 70 000 mW
Red Power: 29 000 mW / 638 nm
Green Power: 29 000 mW / 520 nm
Blue Power: 29 000 mW / 450 nm
Beam Diameter: 10.0 mm
Beam Divergence: 1.1 mrad
Scanner Speed: 30 kpps @ 8°
Max Scan Angle: 60°
Laser Source: Diode
Laser Class: 4
Control Modes: ILDA, DMX, ArtNet, LAN, SD card, stand-alone
IP Rating: IP65
Power Supply: 85–250 V AC, 50/60 Hz
Power Consumption: 1000 W
Dimensions (L×W×H): 834 × 524 × 270 mm
Weight: 70 kg
Included Accessories: Waterproof flightcase, power cable, manual, interlock, key

Related Documents

Laserworld PL-70.000RGB IP65 – User Manual
