The Laserworld ScanBar 10RGB is a powerful 10-watt full-colour laser bar that delivers striking aerial beam effects through five individually scanned RGB apertures, making it ideal for venues of any size. Each diode module features a fast 25 kpps X/Y scanner that produces sharp, low-divergence beams, while more than 100 built-in patterns—such as waves, fans, and tunnels—enable dynamic stand-alone visuals or integration into time-coded shows. Designed for seamless control, it offers four DMX profiles, analogue colour modulation for smooth gradients, and master-slave capability for synchronized multi-fixture setups. Housed in a durable 1-metre aluminium chassis with an auto-sensing 85–250 V power supply, safety interlock, and Class 4 certification, the ScanBar 10RGB is built for reliable touring and professional event use.
Laserworld ScanBar 10RGB Laser (Red, Green, Blue)
RRP:
Key Features:
- 10 W white-light RGB output with ultra-low divergence
- Five independent X/Y scanners generate dynamic multi-beam shows
- Full analogue colour mixing plus 100+ built-in patterns
- Four DMX profiles for seamless integration into any lighting rig
- Rugged 1 m aluminium bar housing built for touring
- Supports stand-alone, master-slave & DMX control
Technical Data
| Guaranteed Power: | 10,000 mW (10 W) |
|---|---|
| Laser Sources: | 5 × RGB diode modules |
| Red Laser Power: | 5 × 450 mW / 638 nm |
| Green Laser Power: | 5 × 600 mW / 525 nm |
| Blue Laser Power: | 5 × 950 mW / 450 nm |
| Beam Specifications: | 4 mm / 1.1 mrad |
| Scanners: | 5 × X/Y scanners, 25 kpps at 8° |
| Modulation: | Analog, full-colour mixing |
| Operation Modes: | DMX, stand-alone, master-slave |
| DMX Profiles: | 4 integrated |
| Internal Patterns: | More than 100 |
| Laser Class: | Class 4 |
| Power Supply: | 85–250 V AC, 50/60 Hz |
| Power Consumption: | 150 W |
| Dimensions: | 1000 × 152 × 105 mm |
| Weight: | 12 kg |
| Included Accessories: | Power cable, interlock, safety key, manual |
