The Power Dynamics 176730 Combi Cable simplifies lighting setups by combining power and DMX signal transmission into a single rugged cable. Designed for professional LED effects, moving heads and wall washers, this compact 2 m combi cable reduces cable clutter and speeds up installation for live events, touring rigs and permanent lighting installations. Featuring Powerconnector TR and 3-pin XLR IP65 connectors on both ends, it delivers secure and reliable power and signal connectivity while supporting easy daisy-chaining between fixtures. The durable 3 × 1.5 mm² power conductors handle up to 16 A, while the shielded signal conductors ensure stable DMX performance with minimal interference. Its IP65-rated construction offers added protection against dust and moisture, making it suitable for both indoor and outdoor applications.
Power Dynamics 176730 Combi Cable Powerconnector TR – XLR (2m)
RRP: $69.00 ex. GST
Key Features:
- Combines power and DMX signal in a single cable
- Designed for LED effects, moving heads and wall washers
- Powerconnector TR and 3-pin XLR IP65 connectors on both ends
- Supports easy daisy-chaining between lighting fixtures
- 3 × 1.5 mm² power conductors support up to 16 A
- Shielded signal conductors help minimise interference
- IP65-rated connectors protect against dust and moisture
- Compact 2 m length ideal for tidy stage and truss setups
Technical Data
| Product Colour | Black |
|---|---|
| Length | 2 m |
| Lead Length | 0.35 m |
| Power Cable | 3 × 1.5 mm² |
| Signal Conductor | 8 × 0.2 mm |
| Outer Diameter | 10.8 mm |
| Shielding | 64 × 0.08 mm |
| Impedance | 120 Ohm |
| IP Rating | IP65 |
| Connectors | Powerconnector TR IP65 A/B, 3-pin XLR IP65 Male/Female |
| Weight | 0.20 kg |
