The Power Dynamics PD18NW is an 18-inch woofer for subwoofer cabinets, including bass-reflex and band-pass designs. It uses a 4-inch (100mm) inside-outside copper voice coil, a neodymium magnet and a double spider construction with silicone-based dampening. The glass-fibre loaded waterproof cone and aluminium basket support the stated high-power design, while the aluminium basket reduces magnetic interference. It has a maximum output power of 2000W and RMS output power of 1000W.
Power Dynamics PD18NW 18-inch Neodymium Woofer 2000W
RRP: $539.00 ex. GST
Key Features:
- 4” (100mm) inside-outside copper voice coil
- Neodymium Magnet
- Double spider construction with silicone-based dampening
- Aluminium basket reduces magnetic interference
- Glass-fibre loaded waterproof cone
- Suitable for the most subwoofer cabinets
Technical Data
| Product colour | Black |
| Output power: Max | 2000W |
| Output power: RMS | 1000W |
| Diameter woofer | 18″ |
| Voice coil | 4″ |
| Frequency response | 41Hz – 2000Hz |
| SPL @ 1W/1m | 98dB |
| Impedance | 8 Ohm |
| Mounting diameter | 424mm |
| Mounting depth | 196mm |
| Dimensions (L x W x H) | 460 x 460 x 180 |
| Weight (kg) | 9.95 |
