The Chauvet DJ Sentinel Wash Q7Z ILS is a compact moving head wash fixture featuring 20 W quad-color RGBW LEDs and a motorized zoom that adjusts beam angles from 5° to 27° for both short-throw and long-throw use. It includes a built-in D-Fi transceiver for wireless DMX or ILS signal communication and supports power linking to reduce cable clutter. The fixture offers easy control through a full-color LCD display and integrates with the ILS ecosystem, including a Totem Mode that keeps lighting focused on the dance floor. It is designed for flexible professional lighting setups with reliable performance and efficient deployment.
Chauvet DJ SENTINELWASHQ7Z-ILS Moving-head Wash Fixture
RRP: $1,099.00 ex. GST
Key Features:
- Compact moving head wash fitted with 20 W quad-color RGBW LEDs
- Motorized zoom for short-throw or long-throw applications
- Built-in DFI transceiver communicates DMX or ILS signals wirelessly
- Easy navigation and access all functions directly from the full-color LCD display
- ILS compatibility for use in the ILS ecosystem
- Totem Mode keeps the moving head focused on the dance floor
- Save time running cables and extension cords by power linking multiple units
- Fits best in the CHS-40 VIP Gear Bag
Technical Data
| DMX Channels | 9 or 14 |
| DMX Connectors | 3-pin XLR |
| Pan and Tilt | 540°/225° |
| Pan and Tilt Ranges | 180°, 360°, 540° pan / 90°, 180°, 225° tilt |
| Light Source | 7 LEDs (quad-color RGBW) 140 W total (5 A), 50,000 hours life expectancy |
| Strobe Rate | 0 to 20 Hz |
| Zoom Angle | 5° to 27° |
| Illuminance Narrow | (5°) 30,537 lux @ 2m |
| Illuminance Wide | (27°) 3,390 lux @ 2m |
| Cable Length | 5 ft (1.5 m) |
| Power Linking | 6 units @ 120 V; 12 units @ 230 V |
| Input Voltage | 100 to 240 VAC, 50/60 Hz (auto-ranging) |
| Power and Current | 148 W, 1.2 A @ 120 V, 60 Hz |
| Power and Current | 146 W, 0.7 A @ 230 V, 50 Hz |
| Weight | 13.8 lb (6.3 kg) |
| Size | 4.5 x 2.4 x 1.4 in (115 x 61 x 35 mm) |
| Optional Controllers | IRC-6, ILS Command |
| Approvals | CE, RoHS, FCC |
